Purpose-Built for Pipe Welding

This excellent engine driven welder/generator is capable of DC multi-purpose welding, 120/240 VAC single phase, and 240 VAC three phase auxiliary power. Designed for pipeline welding, the Cross Country® 300 features dual output control to fine-tune the welding arc, all in a compact, lightweight package to fit into truck beds.



Machine Number: K4166-1

What’s included:

  • (1) Cross Country® 300 (Kubota®)

The images shown are for representation purposes only and may not reflect the actual product.

Machine Processes:Stick (SMAW), Gouging (CAC-A), TIG (GTAW), MIG (GMAW), Flux-Cored Self-Shielded (FCAW-S), Flux-Cored Gas-Shielded (FCAW-G)
Open Circuit Voltage:80 Peak OCV @ 1800 RPM
Single Phase Auxiliary Output:10,000 Watts Continuous, 11,500 Watts Peak, 120/240V
Three Phase Auxiliary Output:11,000 Watts Continuous, 12,500 Watts Peak, 240V
Auxiliary Output Frequency:60 Hz
Receptacle Types:NEMA 5-20R, NEMA 14-50R, NEMA 15-50R
Engine Brand & Model:Kubota® V1505
Engine Description:4 Cylinder Naturally Aspirated Water-Cooled Diesel Engine
Engine Horsepower:22.0 HP (16.4 kW)
Engine Block Size & Displacement:91.4 cu. in (1.5 L), Bore x Stroke – 3.07 in x 3.09 in (78 mm x 78 mm)
Emissions Rating:US EPA Tier 4 Final
High Idle Operating Speed @ Rated Output:1800 RPM
Low Idle Operating Speed:1350 RPM
Fuel Tank Size:11.6 gal., 44 L
Oil Capacity:6.4 qts., 6.0 L
Coolant Capacity:1.2 gal., 4.5 L
Warranty:3 Years Parts and Labor – Engine warranted separately by engine manufacturer

Unit Dimensions (H x W x D): 31.9 in. x 25.3 in. x 56.0 in. (810 mm x 643 mm x 1422 mm)

Net Weight: 1034 lbs. (469 kg)

Vanair®, the Vanair® logo and Mobile Power Solutions® are registered trademarks or trademarks of Vanair®, a Lincoln Electric Company, Michigan City, IN, USA. Lincoln Electric®, Cross Country®, and the Stacked Oval Logo are registered trademarks of The Lincoln Electric Company and its related companies. All trademarks and registered trademarks are the property of their respective owners.

IEC Rating:300A / 32V / 100% @ 104°F (40°C)
Output Range by Mode: CC-Stick: 40–300A, Touch Start TIG: 20-250A, CV-Wire: 14–32V
Rated Gouging Carbon Diameter:1/4 in. (6.5 mm)
  • It’s All About the Arc – Out on the pipeline spread, your job depends on whether each and every weld passes inspection. The Cross Country® 300 stick arc was tuned by pipeline welders for pipeline welders. That means puddle performance is excellent for root, fill, and cap passes and designed for cellulosic or low hydrogen stick electrodes.
  • The Size is Right – On remote job sites, you have to carry everything with you. This puts space on your rig at a premium. The Cross Country® 300 is the most compact engine driven pipe welder in its class and easily fits on most trucks. That means you get a small footprint, short height for great visibility through the truck’s rear window, and lower weight to go easier on your truck’s suspension. The powder-coated steel enclosure and polished stainless steel exhaust stack will look great on your rig and will stand up to years of cross-country travel. The new heavy-duty stainless-steel case and rugged wired or wireless remotes add to the durability and utility of these welders.
  • Easy To Use – It’s easy to get started with the Cross Country® 300. Dual continuous controls designed for pipeline welding help you tune the arc for the pipe, pass, position, conditions and more. Fewer controls improve simplicity and reliability. Service access for routine maintenance is easy, even on the truck, with sliding engine access doors on each side of the machine. Battery jumper studs are also conveniently located. Digital meters and dashboard gauges monitor key functions.
  • Flexible – When your project calls for wire or TIG welding, you’ll be ready. The Cross Country® 300 supports DC stick, wire and TIG processes and easily connects to Lincoln Electric wire feeders. The powerful generator produces plenty of power for grinders, pumps and travel trailers – up to 11kW continuous three phase power. An engine block heater, standard equipment on the Cross Country 300, enables operation in cold weather environments.
  • Construction
  • Cross Country Pipeline
  • Construction & Field Erection
  • High-strength Pipe
  • Maintenance & Repair
  • Oil & Gas
  • Pipeline & Offshore
  • Piping
  • Power Generation
  • Structural Fabrication
  • K4166-1 — Cross Country® 300 (Kubota®) Engine Driven Welder/Generator

3 Years Parts and Labor – Engine warranted separately by engine manufacturer https://www.lincolnelectric.com/en/Legal-Information/Warranty-Statements
