Dependable Air, Proven Compressor Choice!

When you need Clean, Quiet, Power™ with no fumes or extensive heat build-up, the EPEQ® AIR20 is your proven compressor choice. EPEQ® Air Compressors are designed to be ultra-efficient when paired with the ELiMENT® Battery. The EPEQ® AIR20 reciprocating compressor provides 20 CFM at 150 PSI, which is ideal for intermittent air use while performing tire service or operating air tools. The 48V, permanent magnet AC (PMAC) electric motor mounts below the compressor for clean, compact installation. The AIR20 compressor communicates to the EPEQ® Smart Controller and is designed to extend battery life and provide optimal performance.

The “smart” LiFePO4 ELiMENT® Battery contains multiple individual cells that are monitored by the BMS. ELiMENT® batteries are designed to fit in compact spaces, including a service body side-pack or van shelving package, are easily mounted, and include quick connect plugs for ease of installation and relocation. A one-of-a-kind BMS monitors multiple individual battery cells and can discharge power while being charged back simultaneously.



EPEQ® AIR20 PERFORMANCE AND SPECIFICATIONS

  • Clean, Quiet Operation
  • Auto Throttle Control on Air Compressor
  • Heavy Duty Belt Drive System for Anti-Vibration and Long Service Intervals
  • Completely Self Contained
  • Designed for Easy Maintenance
  • Powder Coated Sheet Metal
  • Galvannealed Steel
  • Communicates with the EPEQ® Smart Controller which is powered by the ELiMENT® Battery and EPEQ® BMS for Superior Performance
Contact Us
EPEQ® AIR20
TypeSpecification
Motor Permanent Magnet AC (PMAC) Electric
Compressor TypeReciprocating
CFM RatingTwo Speed; 10 CFM and 20 CFM
Max Rated PSI150 PSI
Drive SystemDual V-Belt
Capacity100 Ah
Low Speed Run Time120 Minutes
High Speed Run Time60 Minutes
Size19” L x 14” W x 24” H
Weight90 lbs.

ELiMENT® Battery

TypeSpecification
Capacity100 Ah
Voltage48
Cycles5,000
MaterialLithium Iron Phosphate
ProtectionsOver-Current, Short-Circuit, Over-Charge, Over-Discharge, Over-Temperature and Under-Temperature
EPEQ® Battery Management SystemIncluded
Size13.38” L x 12.5“ W x 11.8“ H with Handles
Weight107 lbs.

EPEQ® Shore Power Charger

TypeSpecification
VAC120
Size11” L x 4” W x 8” H
Weight10 lbs.

EPEQ® Smart Controller

TypeSpecification
DisplayLED with Anti-Glare Coating
WaterproofIP67 Rated
Reads and ReportsState of Charge, Charge / Discharge Rates and Cycles, Cell Voltage Levels, Battery Temperature
Faults and WarningsOver-Charge and Over-Discharge, Over-Temperature and Under-Temperature
