EPEQ® Light Duty/ Service and Maintenance Vehicle Kit

(1) ELiMENT® Battery

• Capacity: 100 Ah
• Voltage: 48
• Cycles: 5,000
• Material: Lithium Iron Phosphate
• Protections: Over-Current, Short-Circuit, Over-Charge, Over-Discharge, Over-Temperature, and Under-
  Temperature
• EPEQ® Battery Management System
• Size: 13” L x 13“ W x 12“ H with Handles
• Weight: 107 lbs.

(1) EPEQ® AIR20 Compressor

• Motor: PMAC
• Compressor Type: Reciprocating
• Two Speed; 10 CFM and 20 CFM
• 150 PSI Maximum
• Drive System: Dual V-Belt
• Capacity: 100 Ah
• Low Speed Run Time: 120 Minutes
• High Speed Run Time: 60 Minutes
• Size: 19” L x 14” W x 24” H
• Weight: 90 lbs.

(1) EPEQ® INVERTER3000

• Watts: 3000
• Input Voltage: 48VDC High-Frequency Topology
• Output: 120VAC Pure Sine Wave
• GFCI Outlet
• Simple Remote Connection to Add Additional Outlets
• Remote On/Off
• Size: 18” L x 5” W x 10” H
• Weight: 10 Lbs.

(1) EPEQ® Shore Power Charger

• 120VAC
• Size: 11” L x 4” W x 8” H
• Weight: 10 lbs.

(1) EPEQ® Smart Display

• LED Display with Anti-Glare Coating
• IP67 Rated
• Reads and Reports:
  – State of Charge
  – Charge / Discharge Rates and Cycles
  – Cell Voltage Levels
  – Battery Temperature
• Faults and Warnings:
  – Over-Charge and Over-Discharge
  – Over-Temperature and Under-Temperature

(1) Optional EPEQ® DC-DC Converter

• Optional 12VDC Input to 48V, 20A Output
• Featuring Industry Leading Safeties and Internal Cooling Capabilities
• Size: 10” L x 3” W x 6” H
• Weight: 5 lbs.

(1) Optional Reservoir Tank

• Optional 14 or 20-Gallon Air Reservoir Tank
• Size: 37” L x 15.5” W x 18” H
• Weight: 53 lbs.
